MX-160-LT-8
MX-160-LT-8 is a compact and reasonable VDSL DSLAM / MDU for multi-family residences.
Supports VDSL 2 (30a profile), high speed VDSL connection with copper line is possible. In addition, it supports ADSL 2+, and it can also serve as ADSL 2+ instead of VDSL on long distance lines. A compact enclosure can be installed in a limited space and it is easy to install it in a small cabinet.
Because it supports the optical fiber port (SFP) on the uplink, MX-160-LT-8 is installed in a remote location and connected by fiber, and communication services can be provided by VDSL.
As with the VDSL products of the same series (MX-160, 160-16 P9, it also supports advanced network services of triple play (video, voice, data).
Supports VDSL 2 (30a profile), high speed VDSL connection with copper line is possible. In addition, it supports ADSL 2+, and it can also serve as ADSL 2+ instead of VDSL on long distance lines. A compact enclosure can be installed in a limited space and it is easy to install it in a small cabinet.
Because it supports the optical fiber port (SFP) on the uplink, MX-160-LT-8 is installed in a remote location and connected by fiber, and communication services can be provided by VDSL.
As with the VDSL products of the same series (MX-160, 160-16 P9, it also supports advanced network services of triple play (video, voice, data).
VDSL | 100Mbps, 8Port(RJ45,2wire) |
LAN Interface | 100/1000Mbps, RJ45×1Port,SFP×1Port(SFP Sold Separately) |
Operating Requirements | Temperature: -40~65℃,Humidity:0~85%(Non-Condensing),AC Adapter(0~50℃) |
Physical Specification | Dimensions: 38(H) ×254(W) ×152(D) [mm],Weight: 0.54 [Kg],Power:AC Adapter (100-240V 50/60Hz) |
Management and Network | WEBManagemet/CLI(Telnet・Serial)/SNMP,VLAN,QoS,Bridge,Router |
Compliance | Safety:CSA 22.2No.60950-1,EN60950-1,IEC60950-1,UL60950-1,EMC Emissions:FCC Part15 ClassA,EN55022 ClassA,ICES-003 ClassA,VCCI ClassA,EMC Immunity:EN 300 386v1.4.1,Environmental:ETS 300 019-2-x,ISTA Transportation and Handling |
VDSL Compact Type 100M 8 Lines ADSL Mode
